190kg/H Carbon Rotary Kiln Infrared Temperature Sensing Kiln In Cement Plant
|
190kg/H Carbon Rotary Kiln Infrared Temperature Sensing Kiln In Cement Plant
| Place of Origin | China |
| Brand Name | Zoomline |
| Model Number | YZ1225/1632/1636/1828/2245/2550/3529/3560 |
Product Details
Fuel Consumption:
3-190kg/h
Temperature:
1000-1500℃
Slope:
3.5-4%
Weight:
34-795t
Highlight:
190kg/H Carbon Rotary Kiln
,190kg/H Kiln In Cement Plant
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Wooden box or film
Delivery Time
30-50 days
Payment Terms
T/T
Supply Ability
Negotiable
Product Description
190kg/H Carbon Rotary Kiln Infrared Temperature Sensing Kiln for Cement Plants
This high-performance carbon rotary kiln features infrared temperature sensing technology specifically designed for cement plant applications, offering precise temperature control and efficient operation.
Key Specifications
Fuel Consumption
3-190kg/h
Temperature Range
1000-1500℃
Slope
3.5-4%
Weight
34-795t
Carbon Rotary Kiln Equipment Overview
As a major aluminum industry producer, our country relies heavily on carbon products for aluminum smelting. With the rapid development of the aluminum electrolysis industry, carbon rotary kilns for calcining carbon materials have become essential production equipment.
Innovative Design Features
- Optimized kiln tail diameter and structure
- Enhanced feeding pipe installation position
- Integrated sedimentation combustion chamber
- Advanced material recovery system
Performance Advantages
- Stable performance with low energy consumption and high output
- Simple operation with reliable process control
- Minimal wearing parts for higher operation rates
- Incorporates advanced technologies including hydraulic wheel devices and high-precision metering systems
- 10% higher operation rate compared to similar equipment
- 5-10% increased production output
- 15% reduction in heat consumption
Technical Specifications
| Model | Barrel Diameter (mm) | Barrel Length (mm) | Slope (%) | Capacity (t/h) | Speed (r/min) | Motor Power (kW) | Weight (t) |
|---|---|---|---|---|---|---|---|
| YZ1225 | 1200 | 25000 | 4 | 3 | 0.35 - 3.55 | 15 | 34 |
| YZ1632 | 1600 | 32000 | 4 | 3.5 | 0.53 - 5.25 | 22 | 46.82 |
| YZ1636 | 1600 | 36000 | 4 | 1.2 - 1.9 | 0.26 - 2.61 | 22 | 51.023 |
| YZ1828 | 1800 | 28000 | 4 | 4 | 0.28 - 2.84 | 30 | 59.39 |
| YZ1845 | 1800 | 45000 | 4 | 4.5 | 0.28 - 2.84 | 30 | 80 |
| YZ1939 | 1900 | 39000 | 4 | 1.6 - 3.4 | 0.31 - 2.82 | 37 | 70.704 |
| YZ2044 | 2000 | 44000 | 3.5 | 2.4 - 4 | 0.22 - 2.26 | 37 | 97.135 |
| YZ2245 | 2200 | 45000 | 3.5 | 3.2 - 5.3 | 0.23 - 2.25 | 45 | 125.462 |
| YZ2550 | 2500 | 50000 | 3.5 | 6.2 - 7.4 | 0.68 - 1.45 | 55 | 179.606 |
| YZ2555 | 2500 | 55000 | 3.5 | 7.3 - 9.8 | 0.79 - 2.38 | 55 | 191.203 |
