Carbon Steel Rotary Dryer Machine Adjustable Speed Rotating Dryer
| Place of Origin | China |
| Brand Name | Zoomline |
| Model Number | ZT-1.5*12 1.8*14 2.4*18 |
Product Details
Capacity:
Customizable
Size:
Customizable
Heating Method:
Direct Or Indirect
Application:
Drying Of Bulk Materials
Safety Features:
Emergency Stop, Temperature Control, Etc.
Speed:
Adjustable
Material:
Carbon Steel
Power Supply:
Electric Or Gas
Highlight:
Carbon Steel Rotary Dryer Machine
,Adjustable Speed Rotating Dryer
,Rotary Dryer Machine Adjustable
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Wooden box or film
Delivery Time
30-50 days
Payment Terms
T/T
Supply Ability
Negotiable
Product Description
Customizable Drying Rotary Dryer Industrial Rotary Dryer System
Key Specifications
| Capacity | Customizable |
| Size | Customizable |
| Heating Method | Direct or Indirect |
| Application | Drying of Bulk Materials |
| Safety Features | Emergency Stop, Temperature Control |
| Speed | Adjustable |
| Material | Carbon Steel / Stainless Steel |
| Power Supply | Electric or Gas |
| Warranty | 1 Year |
| Installation | Stationary or Portable |
Industrial Rotary Dryer Overview
Our rotary drum dryer serves as core equipment for industrial drying applications, precisely engineered to meet diverse material drying requirements. This system ensures efficient, stable drying operations to achieve optimal moisture content for subsequent production processes.
Working Principle
The rotary dryer operates through a carefully designed system comprising a rotating drum, driving mechanism, feeding/discharging devices, and heating components. Wet materials enter the inclined drum where they are continuously lifted and dropped while exposed to high-temperature airflow. This process facilitates rapid moisture evaporation and uniform drying before discharge.
Performance Advantages
- High-Efficiency Drying: Unique drum design maximizes material-air contact for rapid moisture removal across various material types
- Uniform Drying: Continuous rotation ensures consistent drying results with minimal quality variation
- Material Adaptability: Adjustable parameters accommodate heat-sensitive materials and high-moisture content
- Energy Efficient: Optimized heat exchange system minimizes energy waste while maintaining performance
- Environmentally Compliant: Integrated dust collection reduces particulate emissions
Technical Specifications
| Model | Inside Dia. (m) | Length (m) | Gradient (%) | Rotate Speed (r/min) | Power (kW) | Capacity (t/h) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| ZT-1.2×6/8 | 1.2 | 6/8 | 5.0 | 5.8 | 5.5 | 8-12 | 9380/10200 |
| ZT-1.5×12/15 | 1.5 | 12/15 | 5.0 | 4.8 | 15 | 12-16 | 16450/18240 |
| ZT-1.8×12/14 | 1.8 | 12/14 | 5.0 | 4.5 | 18.5 | 18-20 | 20000/21000 |
| ZT-2.2×12/14 | 2.2 | 12/14 | 5.0 | 4.3 | 22 | 22-28 | 30500/32000 |
| ZT-2.4×14 | 2.4 | 14 | 4.0 | 3.78 | 30 | 30-35 | 46000 |
| ZT-2.4×18 | 2.4 | 18 | 4.0 | 3.0 | 37 | 35-40 | 50000 |
| ZT-2.4×22 | 2.4 | 22 | 3.0 | 3.0 | 45 | 38-42 | 54000 |
| ZT-2.8×20 | 2.8 | 20 | 4.0 | 3.7 | 40 | 45-55 | 75000 |
| ZT-3.0×22/25 | 3.0 | 22/25 | 4.0 | 3.2 | 75 | 58-70 | 80000/87000 |
| ZT-3.2×25 | 3.2 | 25 | 4.0 | 3.0 | 110 | 75-90 | 116000 |
| ZT-3.6×25 | 3.6 | 25 | 4.0 | 2.7 | 132 | 95-110 | 146000 |
Product Images
Customization Options
Our rotary dryers offer extensive customization including size, heating method (direct/indirect), control system (manual/automatic), and installation configuration (stationary/portable). Manufactured in Henan, China, these systems are built for durability and long-term performance in demanding industrial environments.
Note: Technical specifications subject to change without prior notice. Contact our engineering team for project-specific requirements.
