Easy To Maintain Rotary Dryers Customizable Rotary Air Dryer
| Place of Origin | China |
| Brand Name | Zoomline |
Product Details
Control System:
Manual Or Automatic
Power Supply:
Electric Or Gas
Type:
Industrial Dryer
Safety Features:
Emergency Stop, Temperature Control, Etc.
Material:
Carbon Steel
Warranty:
1 Year
Maintenance:
Easy To Maintain
Heating Method:
Direct Or Indirect
Highlight:
Easy To Maintain Rotary Dryers
,Customizable Rotary Air Dryer
,Rotary Dryers Customizable
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Wooden box or film
Delivery Time
30-50 days
Payment Terms
T/T
Supply Ability
Negotiable
Product Description
Emergency Stop Rotary Dryers Customizable Adjustable Speed Rotary Air Dryer
Rotary Dryers are among the most versatile and efficient industrial drying solutions available. Designed for diverse applications, they deliver exceptional performance for industries requiring reliable, high-capacity drying processes.
Product Attributes
| Attribute | Value |
|---|---|
| Control System | Manual Or Automatic |
| Power Supply | Electric Or Gas |
| Type | Industrial Dryer |
| Safety Features | Emergency Stop, Temperature Control, Etc. |
| Material | Carbon Steel |
| Warranty | 1 Year |
| Maintenance | Easy To Maintain |
| Heating Method | Direct Or Indirect |
Key Features
- Product Name: Rotary Dryers
- Installation: Stationary Or Portable
- Control System: Manual Or Automatic
- Material: Stainless Steel
- Warranty: 1 Year
- Speed: Adjustable
Technical Parameters
| Parameter | Details |
|---|---|
| Safety Features | Emergency Stop, Temperature Control, Etc. |
| Installation | Stationary Or Portable |
| Type | Industrial Dryer |
| Application | Drying Of Bulk Materials |
| Control System | Manual Or Automatic |
| Size | Customizable |
| Capacity | Customizable |
| Maintenance | Easy To Maintain |
| Material | Stainless Steel |
| Speed | Adjustable |
Applications
Rotary Dryers are versatile industrial dryers designed for efficient bulk material drying across various industries. Originating from Henan, China, these dryers are renowned for their high performance and reliability in processing minerals, chemicals, fertilizers, and other materials.
Customization
- Brand Name: Rotary Dryers
- Place of Origin: Henan, China
- Capacity: Customizable
- Installation: Stationary Or Portable
- Heating Method: Direct Or Indirect
- Size: Customizable
- Maintenance: Easy To Maintain
Technical Specifications
| Model | Inside dia. (m) | Length (m) | Gradient (%) | Rotate speed (r/min) | Power (kw) | Capacity (t/h) | Weight (kg) |
|---|---|---|---|---|---|---|---|
| ZT - 1.2×6/8 | 1.2 | 6/8 | 5.0 | 5.8 | 5.5 | 8 - 12 | 9380/10200 |
| ZT - 1.5×12/15 | 1.5 | 12/15 | 5.0 | 4.8 | 15 | 12 - 16 | 16450/18240 |
| ZT - 1.8×12/14 | 1.8 | 12/14 | 5.0 | 4.5 | 18.5 | 18 - 20 | 20000/21000 |
| ZT - 2.2×12/14 | 2.2 | 12/14 | 5.0 | 4.3 | 22 | 22 - 28 | 30500/32000 |
| ZT - 2.4×14 | 2.4 | 14 | 4.0 | 3.78 | 30 | 30 - 35 | 46000 |
| ZT - 2.4×18 | 2.4 | 18 | 4.0 | 3.0 | 37 | 35 - 40 | 50000 |
| ZT - 2.4×22 | 2.4 | 22 | 3.0 | 3.0 | 45 | 38 - 42 | 54000 |
| ZT - 2.8×20 | 2.8 | 20 | 4.0 | 3.7 | 40 | 45 - 55 | 75000 |
| ZT - 3.0×22/25 | 3.0 | 22/25 | 4.0 | 3.2 | 75 | 58 - 70 | 80000/87000 |
| ZT - 3.2×25 | 3.2 | 25 | 4.0 | 3.0 | 110 | 75 - 90 | 116000 |
| ZT - 3.6×25 | 3.6 | 25 | 4.0 | 2.7 | 132 | 95 - 110 | 146000 |
Note: Any change of technical data shall not be advised additionally.
