Fluidized Bed Roaster
>
Microwave Fluidized Bed Roasting 0.05mm To 3mm Particle Fluid Bed Boiler System
|
Microwave Fluidized Bed Roasting 0.05mm To 3mm Particle Fluid Bed Boiler System
| Place of Origin | China |
| Brand Name | Zoomline |
Product Details
Particle Size Range:
0.1-5 Mm
Residence Time:
5-30 Minutes
Scale-Up Potential:
High
Automation Level:
High
Material:
Solid Particles
Environmental Impact:
Low
Maintenance Cost:
Low
Uniformity Of Roasting:
High
Highlight:
Microwave Fluidized Bed Roasting
,Fluidized Bed Roasting 0.05mm particle
,3mm particle fluid bed boiler
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Wooden box or film
Delivery Time
30-50 days
Payment Terms
T/T
Supply Ability
Negotiable
Product Description
Microwave Fluidized Bed Roasting 0.05mm To 3mm Particle Fluid Bed Boiler System
System Overview
The microwave-enhanced fluidized bed roasting system is engineered for high-efficiency mineral processing, featuring a 2.45 GHz microwave array that increases reaction efficiency by 35%. With wear-resistant silicon carbide lining for extended durability, this system excels in zinc concentrate processing for rapid desulfurization.
System Specifications
| Attribute | Value |
|---|---|
| Particle Size Range | 0.1-5 Mm |
| Residence Time | 5-30 Minutes |
| Scale-Up Potential | High |
| Automation Level | High |
| Material | Solid Particles |
| Environmental Impact | Low |
| Maintenance Cost | Low |
| Uniformity Of Roasting | High |
Key Features
- Conical expansion structure increases gas retention time by 30% for superior heat transfer
- Dual heating technology combining gas and microwave power for flexible operation
- Real-time microwave power adjustment for optimal process control
Performance Advantages
- Exceptional desulfurization efficiency exceeding 98.5% sulfur removal
- 22% reduction in energy consumption compared to conventional systems
- Coke-free operation ensured by patented fluidizing plate design
Model Specifications
| Model | Diameter (mm) | Capacity (t/h) | Power (kW) | Weight (t) |
|---|---|---|---|---|
| ZLFT - 0.6m² | 900 | 0.1 - 1.2 | 5.5 - 7.5 | 3.5 |
| ZLFT - 1.1m² | 1200 | 0.3 - 2.7 | 11 - 15 | 5.9 |
| ZLFT - 3m² | 2000 | 1.1 - 3.5 | 22 - 30 | 17 |
| ZLFT - 5m² | 2600 | 3.8 - 7.9 | 30 - 45 | 26 |
| ZLFT - 16m² | 4600 | 15 - 30 | 90 - 110 | 55 |
| ZLFT - 32m² | 6400 | 26 - 60 | 132 - 180 | 98 |
